Related Projects

Epigenetic Studies

Epigentic Studies

Participants: Paul Gugger, Victoria Sork, Sorel Fitz-Gibbon, Matteo Pellegrini

Species-wide patterns of DNA methylation variation in Quercus lobata and its association with climate gradients

Authors: Paul F. Gugger, Sorel Fitz-Gibbon, Matteo Pellegrini, and Victoria L. Sork
Molecular Ecology, in press

Abstract
DNA methylation in plants affects transposon silencing, transcriptional regulation, and thus phenotypic variation. One unanswered question is whether DNA methylation could be involved in local adaptation of plant populations to their environments. If methylation alters phenotypes to improve plant response to the environment, then methylation sites or the genes that affect them could be a target of natural selection. Using reduced-representation bisulfite sequencing (RRBS) data, we assessed whether climate is associated with variation in DNA methylation levels among 58 naturally occurring, species-wide samples of valley oak (Quercus lobata) collected across climate gradients. We identified the genomic context of these variants referencing a new draft valley oak genome sequence. Methylation data were obtained for 341,107 cytosines, of which we deemed 57,488 as single-methylation variants (SMVs), found in the CG, CHG, and CHH sequence contexts. Environmental association analyses revealed 43 specific SMVs that are significantly associated with any of four climate variables, the majority of which are associated with mean maximum temperature. The 43 climate-associated SMVs tend to occur in or near genes, several of which have known involvement in plant response to environment. Multivariate analyses show that climate and spatial variables explain more overall variance in CG-SMVs among individuals than in SNPs, CHG-SMVs, or CHH-SMVs. Together, these results from natural oak populations provide initial evidence for a role of CG methylation in locally adaptive evolution or plasticity in plant response.

Figure1_epigenetics_hiRes7_wCaption



Data links for this study:
--Valley Oak Genome 0.5 (reduced) FASTA file download
-Valley Oak Genome 0.5 subset annotation gff file download
-SNPs, SMVs, and BAM files at Dryad


Genome-wide signature of local adaptation linked to variable CpG methylation in oak populations

Authors: Alexander Platt, Paul F. Gugger, Matteo Pellegrini, and Victoria L. Sork
Molecular Ecology

Abstract
It has long been known that adaptive evolution can occur through genetic mutations in DNA sequence, but it is unclear whether adaptive evolution can occur through analogous epigenetic mechanisms, such as through DNA methylation. If epigenetic variation contributes directly to evolution, species under threat of disease, invasive competition, climate change or other stresses would have greater stores of variation from which to draw. We looked for evidence of natural selection acting on variably methylated DNA sites using population genomic analysis across three climatologically distinct populations of valley oaks. We found patterns of genetic and epigenetic differentiations that indicate local adaptation is operating on large portions of the oak genome. While CHG methyl polymorphisms are not playing a significant role and would make poor targets for natural selection, our findings suggest that CpG methyl polymor-phisms as a whole are involved in local adaptation, either directly or through linkage to regions under selection.

figure2_epigenetics2_wcaption777



Data links for this study:
-Article
-FST and VCF files at Dryad

Provenance Study

Provenance Study

Participants: Jessica Wright, Victoria Sork, Annie Mix, Paul Gugger

A Newly Established Valley Oak Provenance Trial in California
usforestservicebutton777

Our sequenced genome for valley oak is a tool that will allow us to examine closely the relationship between genetic variation across the entire genome, and observed traits from trees in the field. However, trait values are strongly associated with the environment where a tree is found. Therefore, traits need to be evaluated in a common garden setting. In 2012, we collected acorns from 694 maternal trees from 95 different collecting sites across the range of the species (see map below). The seedlings resulting from these acorns were transplanted into two field sites in the winter of 2014/15.

We are collecting trait data on these seedlings, including survival and growth. In addition, we have been examining the phenology of bud burst, and recording when trees start to grow in the spring. Using our reference genome, we plan to collect genomic data from the parental trees, and relate the traits we measured in a the common garden with variation across the entire genome. In this way, we’ll be able to identify SNPs, genes and alleles associated with the observed traits.

All growth data from the provenance test will be available publicly at the Center for Forest Provenance Data found here as well as the USFS R&D data archive.

Publications:
1) Delfino-Mix A, JW, PF Gugger, C Liang, VL Sork. In press. Establishing a range-wide provenance test in valley oak (Quercus lobata Née) at two California sites. Proceedings of the 7th California Oak Symposium: Managing Oak Woodlands in a Dynamic World. Visalia, CA. PDF link

2) Albarrán-Lara AL, JW Wright, PF Gugger, A Delfino-Mix, JM Peñaloza Ramírez, VL Sork. In press. Phenotypic variation in California populations of valley oak (Quercus lobata Née) along three elevation transects. Proceedings of the 7th California Oak Symposium: Managing Oak Woodlands in a Dynamic World. Visalia, CA. PDF link

Oak Provenance CaliMap
provenance2
provenance1
Oak Provenance seedlingphoto
Valley Oak Phenology
Valley Oak Phenology
Photographs on this page are for the valley oak tree, #786, sequenced for the whole genome project at Sedgewick Reserve in Santa Barbara, CA. Photographs were taken by Andy Lentz to show the change in phenology for this individual in the spring of 2016.

Images on the right side of the page show bud development.

January 18, 2016
786ed_1_18_16_lowerDPI

January 21, 2016
786ed_1_21_16
786ed_1_21_16_buds_lowDPI

January 25, 2016
786ed_1_25_16_lowDPI
786ed_1_25_16_buds_lowDPI

January 28, 2016
786ed_1_28_16
786ed_1_28_16_buds_lowDPI

February 1, 2016
786ed_2_1_16_lowDPI
786ed_2_1_16_buds_lowDPI

February 4, 2016
786ed_2_4_16_lowDPI
786ed_2_4_16_buds_lowDPI

February 8, 2016
786ed_2_8_16_lowDPI
786ed_2_8_16_buds_lowDPI

February 15, 2016
786ed_2_15_16
786ed_2_15_16_buds

February 18, 2016
786ed_2_18_16
786ed_2_18_16_buds

February 19, 2016- buds only
786ed_2_19_16_buds1
786ed_2_19_16_buds2

February 22, 2016
786ed_2_22_16_lowDPI
786ed_2_22_16_buds_lowDPI

February 29, 2016
786ed_2_29_16Best
786ed_2_29_16_buds1_lowDPI

March 3, 2016
786ed_3_3_16no2
786ed_3_3_16_buds

March 10, 2016
786ed_3_10_16highDPI
786ed_3_10_16buds3

March 21, 2016
786ed_3_21_16
786ed_3_21_16_leaves2

March 28, 2016
786ed_3_28_16
786ed_3_28_16_leaves5

April 7, 2016
786ed_4_17_16
786ed_4_17_16_leaves1

May 6, 2016
786ed_5_6_16_tree
786ed_5_6_16_leaves1

May 27, 2016
786ed_5_27_16_tree2
786ed_5_27_16_leaves3
